| Quantity: | |
|---|---|
Center Space | 5.00mm |
Wire Range | 22-14AWG |
Screw Torque | 5lbf.in |
Rated Current | 300V,10A |
Surge Voltage | 4000V |
Insulation Body | PA66,UL94,V-0 |
Screw Material | M3,STEEL |
Terminal Body | BRASS |
Temperature | -40°C105°C |
FE 3-5.00-11-XX
Our PCB mount screw terminal connectors deliver exceptionally reliable wire connections designed specifically for complex industrial environments. Engineered with European standard compatibility, these versatile components provide stable signal and power transmission across demanding PCB board layouts. Equipped with convenient testing holes and a high-density 5.00mm spacing, our premium connectors streamline your on-site maintenance processes while optimizing valuable circuit board real estate. Backed by our robust capabilities as a trusted terminal block supplier, we ensure each unit strictly meets CE certification requirements for long-lasting operational safety and compliance.
Our flame retardant terminal housings utilize high-temperature resistant PA66 nylon to actively prevent dangerous electrical breakdowns during operation. This robust material construction safeguards your sensitive industrial systems against premature aging and harsh chemical corrosion effectively. Furthermore, the carefully selected insulation ensures compliance with RoHS environmental protection requirements for sustainable manufacturing. Operating reliably between -40°C and 105°C, these versatile units maintain exceptional performance integrity during continuous operation across unpredictable environmental conditions.
To accommodate diverse engineering requirements, our flexible modular design supports customized digit configurations ranging from 2P to 24P. This adaptability allows seamless integration into varying equipment layouts depending on your specific wiring needs and project scale. The highly conductive tin-plated brass or phosphor bronze internal components guarantee reliable contact and anti-oxidation properties over extended lifecycles. Ultimately, this comprehensive structural design easily adapts to different wiring demands while providing exceptional anti-vibration stability for moving industrial equipment.
Connecting internal wires becomes remarkably effortless using our intuitive screw crimping method without requiring specialized cold-pressed terminals. This highly efficient mechanism supports both single and multi-strand copper wires while consistently guaranteeing low contact resistance. By eliminating the need for complex specialized tools, this straightforward design facilitates fast wiring, simplifies routine maintenance, and reduces overall on-site construction costs. The precision-engineered cross or straight screws provide optimal tightening torque to prevent accidental loosening during mechanical operation.
Featuring a compact 5.00mm center spacing, our industrial control connectors significantly reduce PCB footprint requirements for modern engineers. This space-saving characteristic makes them exceptionally suitable for compact device designs where internal space remains strictly limited. Additionally, the intelligently integrated testing holes allow technicians to conduct rapid debugging, seamless inspections, and routine maintenance directly on the assembly line. These structural advantages collectively improve overall operation and maintenance efficiency across your entire production floor.
These reliable electrical components serve as the critical power interface for PLC modules, servo drives, and frequency converters. Our PCB screw terminal block solutions perfectly facilitate precise sensor wiring and solenoid valve connections across modern automated manufacturing facilities. Electrical distribution networks, specialized instruments, and security equipment frequently incorporate our precision-engineered connectors for stable internal PCB power routing. Designed meticulously to meet export standards, they guarantee seamless electrical compatibility with standard equipment throughout the European Union market.
Xinlianchuangfu proudly deploys more than 100 automatic assembly machines to ensure consistent, large-scale production for our global partners. We independently developed advanced multi-material stamping dies to maximize manufacturing efficiency and minimize component variations during continuous production runs. This strong commitment to process innovation places our factory firmly in the leading position for automation coverage within the terminal industry. Our efficiency-driven manufacturing approach consistently delivers superior copper-iron binding parts with unparalleled speed and precision.
Providing comprehensive electrical system connection solutions, our custom manufacturing operations strictly adhere to international technical standards. Partnering with our specialized facility guarantees reliable product quality that has successfully passed rigorous UL, CE, and CQC certifications. We continuously integrate new product development with user-centric services to supply highly tailored solutions for your unique power electronics requirements. By maintaining this dependable partnership guarantee, we strive to build a smarter, more sustainable collaborative future together.
Our terminals accept single or multi-strand copper wire. The supported cross-sectional area covers 0.5-3 mm, corresponding to 22-12 AWG. No cold crimping is required.
The rated current is 24 A, and the rated voltage operates at 400 V. Insulation withstand voltage reliably reaches AC 2000 V/1 min.
The external shell utilizes PA66 nylon, achieving a UL94 V-0 flame retardant grade. Internal conductive parts feature highly durable tin-plated brass or phosphor bronze.
The recommended tightening torque remains between 0.6-0.8 Nm. Proper torque prevents poor contact while protecting the delicate threads and casing from physical damage.
