Product Parameters
Rated Current | 600V, 65A |
Wire Range | 24 - 6AWG |
Insulation Body | PA66(UL94 V - 0) |
Material Group | I CLASS |
Pollution Degree | 3 |
Screw Material | M4, BRASS |
Screw Torque | 1.5~1.8N·m |
Surge Voltage | 8000V |
Stripping Length | 10mm |
FS-10N Product Diagram
With a slim 12mm width (25% narrower than standard 10A terminals) and operating temperature range of -40℃ to 105℃, it fits into dense control panels or slim device casings (e.g., smart thermostat enclosures, retail display controllers). Constructed with UL94 V-0 flame-retardant PA66 insulation and corrosion-resistant brass terminals, it meets global safety standards, while its 3500V surge voltage resistance shields connected components (e.g., LED drivers, IoT sensors) from transient electrical spikes. Whether powering commercial electronics or light industrial tools, the RKM-10N prioritizes space efficiency without compromising reliability.
Slim PA66 Insulation: High-strength PA66 thermoplastic with UL94 V-0 flame retardancy reduces installation width to 12mm, fitting into 15mm-wide enclosures (e.g., smart home device casings). The material resists mild chemicals, heat, and mechanical wear, preventing short circuits in tight wiring clusters.
Brass Terminals: Corrosion-resistant brass ensures low electrical resistance (＜0.002Ω per terminal), minimizing heat generation during 10A operation. Unlike aluminum, brass maintains conductivity and structural integrity for up to 10 years in indoor environments.
Zinc-Plated Steel Screws: M2.5 zinc-plated screws add rust resistance, making the terminal suitable for humid indoor spaces (e.g., retail refrigeration controls, bathroom smart mirrors) where moisture could degrade standard steel.
Medium-Power Rating: 300V/10A capacity fits applications like 12V DC LED lighting arrays (5A), 24V DC small water pumps (8A), or 5V DC IoT hub power lines (2A)—avoiding overspecification and unnecessary cost.
Surge Protection: Withstands 3500V transient spikes, shielding sensitive devices (e.g., programmable thermostats, barcode scanners) from power grid fluctuations or faulty electrical outlets.
Wire Compatibility: Accepts 30–16 AWG wires, covering ultra-thin sensor data lines (30 AWG) and moderately thick power wires (16 AWG for LED drivers). This eliminates the need for multiple terminal sizes in compact systems.
Tool-Free Alignment: The 5.08mm center space aligns with pre-drilled PCB holes (common in commercial electronics), reducing assembly time. No specialized tools are required—mounts to standard 3.0mm holes with M2.5 screws (not included).
Supports 2P (2-pole) to 5P (5-pole) setups, with total length calculated as L = 5.08mm × Poles. For example, a 3P configuration (15.24mm total length) fits into 18mm-wide enclosures, ideal for smart home device casings.
Retail & Office Devices: Powers POS systems (cash registers, barcode scanners), office printers, and LED display controllers. Its slim width fits inside device casings, while surge protection safeguards against power spikes from shared outlets.
Smart Home Hubs: Connects power and signal wires for smart lighting, doorbell cameras, and temperature sensors. The compact size fits into wall-mounted enclosures, and brass terminals ensure stable IoT data transmission.
Small Manufacturing Auxiliaries: Used in sensor-based sorting machines (e.g., candy packaging lines) and portable power tool charging docks (e.g., battery drills). UL94 V-0 insulation meets workshop safety standards, while zinc-plated screws resist dust and mild oil exposure.
Food Service Equipment: Integrates into commercial coffee machines, small refrigerators, and countertop ovens. The -40℃ to 105℃ range handles temperature fluctuations, and PA66 insulation resists food-grade cleaners.
Home Theater Systems: Connects power wires for LED light strips, AV receivers, and streaming devices. The slim design fits behind entertainment centers, and surge protection prevents damage from thunderstorm-related power surges.
The "10" denotes a 10A current rating, and "N" stands for "narrow-body" (12mm width)—differentiating it from standard RKM-series terminals (e.g., RKM-6N: 6A, 12.7mm width). This combination makes it ideal for medium-power applications where space is constrained.
Yes. Its 300V rating exceeds 240V AC requirements (common in European or commercial US households). For 240V applications (e.g., small space heaters), use 18 AWG wires (within 30–16 AWG range) and tighten screws to 3 lbf·in (max torque) to avoid insulation damage.
It fits standard 3.0mm (0.118-inch) holes, common in PCBs and plastic enclosures. Use M2.5 mounting screws (6–8mm length) and avoid over-tightening—exceeding 3.5 lbf·in can crack the PA66 insulation.
Yes. The M2.5 zinc-plated screws and brass terminals work with both solid (e.g., 22 AWG sensor wires) and stranded (e.g., 16 AWG LED wires) wires. For stranded wires, twist strands tightly before clamping to ensure full contact and prevent fraying.
Total length (L) = Center Space × Poles = 5.08mm × 4 = 20.32mm. Ensure your enclosure has at least 22mm of space (adding 1.68mm for wire clearance) to avoid crowding and short circuits.
